Bentley Arnage & Azure Fuel Pump (Left Hand) - 3Z0201037

Brand Name : Bentley

Part Number : 3Z0201037

Condition : New

Availability : In Stock

Price :$1,350.00

Select Quantity :

Refer to Friend Print

Description

Ensure the high-performance fuel delivery your 6.75L Twin-Turbo Bentley demands with the Genuine PF109203PB (LH) Fuel Pump. This essential Left-Hand in-tank unit is the factory-correct solution for Arnage, Azure, and Brooklands models from 2002 to 2011 (Chassis 12000 onwards). Now updated to the latest spec 3Z0201037, it replaces all previous iterations including PF102100PC and PF109203PB.

The PF109203PB (superseded by 3Z0201037) is the primary Left-Hand Side (LH) in-tank fuel pump for the modern classic Bentley range.

This specific iteration was introduced for the 2002 Model Year to support the increased demands of the twin-turbocharged 6.75L V8.

Specifically engineered for Chassis numbers 12000 and higher, this genuine unit features the upgraded internal motor assembly designed to resist ethanol-induced degradation. Whether you are maintaining an Arnage T, R, or RL, or the final production Azure and Brooklands models, this pump provides the precise flow rate required by the Bosch engine management system to prevent "Bank 1" lean-run conditions and maintain peak performance at high boost.

Tech Tip:

If your Bentley Arnage has a chassis number lower than 12000, this pump will not fit.

For these earlier cars, you likely require the PF100063 or PF100064 series pumps. When installing the 3Z0201037 in the newer tanks, ensure the internal plastic baffle is seated correctly; if the pump isn't clicked into its base, you will experience fuel starvation when the tank is below 25%, even if the pump itself is running perfectly.
